Traffic Analysis for Cisco 678 RADSL Modem
| System: | Cisco 678 RADSL Modem |
| Interface: | ATM DSL Interface (WAN0-0) |
| IP: | 209.98.144.153 |
| Max Speed: | 1536kbps down/1024kbps up |
The statistics were last updated Thursday, 2 January 2014 at 9:05,
at which time 'dd-wrt' had been up for 16 days, 1:13:22.
`Daily' Graph (5 Minute Average)
|
Max |
Average |
Current |
| In |
0.0 B/s (0.0%) |
0.0 B/s (0.0%) |
0.0 B/s (0.0%) |
| Out |
61.0 kB/s (57.9%) |
18.2 kB/s (17.2%) |
18.1 kB/s (17.2%) |
`Weekly' Graph (30 Minute Average)
|
Max |
Average |
Current |
| In |
0.0 B/s (0.0%) |
0.0 B/s (0.0%) |
0.0 B/s (0.0%) |
| Out |
146.8 kB/s (139.4%) |
25.9 kB/s (24.6%) |
26.7 kB/s (25.4%) |
`Monthly' Graph (2 Hour Average)
|
Max |
Average |
Current |
| In |
0.0 B/s (0.0%) |
0.0 B/s (0.0%) |
0.0 B/s (0.0%) |
| Out |
108.8 kB/s (103.3%) |
23.7 kB/s (22.5%) |
17.5 kB/s (16.7%) |
`Yearly' Graph (1 Day Average)
|
Max |
Average |
Current |
| In |
25.5 kB/s (16.4%) |
592.0 B/s (0.4%) |
0.0 B/s (0.0%) |
| Out |
53.6 kB/s (50.9%) |
8978.0 B/s (8.5%) |
17.5 kB/s (16.7%) |
| GREEN ### |
Incoming Traffic in Bytes per Second |
| BLUE ### |
Outgoing Traffic in Bytes per Second |
| DARK GREEN ### |
Maximal 5 Minute Incoming Traffic |
| MAGENTA ### |
Maximal 5 Minute Outgoing Traffic |
